Schmalz Block Vacuum Cup VCBL-S1 130x30x32.7mm TV is a technical product for professional use in production, servicing and CNC machining.It is suitable for vacuum technology, block vacuum cups and workpiece clamping systems.Technical designations, dimensions, variants and symbols in the product name remain unchanged according to the manufacturer's specification.
Schmalz Block Vacuum Cup VCBL-S1 130x30x32.7mm TV-S is a technical product for professional use in production, servicing and CNC machining.It is suitable for vacuum technology, block vacuum cups and workpiece clamping systems.Technical designations, dimensions, variants and symbols in the product name remain unchanged according to the manufacturer's specification.
Typ-S1 | 360° drehbar
Passt auf alle gängigen SCM-Maschinen*
The product details at a glance.
Construction of SCM block vacuum cup type 1 (S1) and type 4 (S4)
Vacuum pad at the top (1) for fixing the workpiece
Robust base body (2) made of plastic
Dovetail mounting (3) for mechanical pre-fixing on SCM / Morbidelli consoles
Sealing frame (4) optimised for easy sliding of the vacuum cup on the console
Tactile valve (5) for activating the vacuum
Construction of SCM block vacuum pod Type 6 (S6)
- Suction plate with membrane (1) made of elastomer for optimum sealing performance, high friction forces and protection against ingressing chips
- Integrated NFC tag (2) for reading product data via smartphone
- Smooth-running push valve (3) for automatic activation of the vacuum
- Suction cup (4) can be inserted into the vacuum pod mount in 15° increments and fixed by turning the clamping levers (5)
- Robust base body (6) made of glass-fibre reinforced plastic with dovetail mount for fixing to SCM/Morbidelli consoles
