Schmalz Block Vacuum Cup VCBL-K2 PRO 130x30x100 Q TV
€188.60*
% AI Copilot €205.00* AI Copilot (8% saved)Available, delivery time: 1-3 Tage
Qualität & Garantie
Product information "Schmalz Block Vacuum Cup VCBL-K2 PRO 130x30x100 Q TV"
Schmalz 2-circuit Pro block vacuum cup 130x30x100mm Q TV
Version: 2-circuit
Length: 130mm
Width: 30mm
Height: 100mm
Base material: Plastic
Crosswise version
with touch valve
Product features:
- High flexibility: The block vacuum cup is equally suitable for delicate and thin components as well as for rough surfaces and solid wood
- Optimised for high cutting forces: Particularly when machining solid wood, mineral materials and laminated materials, the vacuum cup ensures secure clamping of the workpiece
- Mechanical pre-clamping: Mechanical clamping on the console enables accurate setup, which increases process reliability
- Replaceable components: Both the upper and lower suction plates are available as spare parts, which makes maintenance easier and extends the service life of the vacuum cup
| Number of vacuum circuits: | 2-Kreis |
|---|---|
| PRO: | PRO |
| Suction height: | 100mm |
